PSC Direct Drive Blower Motor - 3/4–1 HP - 115/230V - 1075 RPM
High-efficiency PSC replacement blower motor engineered for simple, true drop-in installation.
The PSC Direct Drive Blower Motor (3/4–1 HP, 115/230V, 1075 RPM) is a versatile, high-efficiency replacement designed to simplify PSC motor changeouts. With adjustable speeds, dual-voltage operation, and a true drop-in design, it delivers reliable airflow performance for residential and light commercial HVAC systems.
Product Overview
The PSC Direct Drive Blower Motor (3/4–1 HP) is designed to replace standard PSC blower motors, reducing inventory while simplifying installation. Two motors can replace virtually any PSC motor up to 1 HP at 115/230V.
Featuring a total of five speed taps—four for W & Y operation plus a 625 RPM constant fan tap—this motor connects directly to the same terminals as a traditional PSC motor for a seamless drop-in replacement.
Motor speed is easily adjusted using the included handheld programmer. Speed percentages can be increased or decreased and permanently stored, allowing precise airflow control across a wide range of HVAC applications.
Features
- Adjustable speeds for optimized airflow
- Four speeds plus 625 RPM constant fan mode
- High efficiency operation: up to 85%
- Multi-horsepower design
- Dual voltage operation: 115V / 230V
- Reversible rotation
- Belly band mount
Specifications
- Horsepower range: 3/4 – 1 HP
- Rated speed: 1075 RPM
- Class B insulation
- Thermal overload protection
- Operating temperature range: -20°C to 55°C (-4°F to 131°F)
- UL Recognized
