1075 RPM Multi-Horsepower Condenser Fan Motor (208–230V, 1/6–1/3 HP)
1075 RPM Multi-Horsepower Condenser Fan Motor (208–230V, 1/6–1/3 HP)
Reliable condenser fan motor engineered for air conditioning and heat pump applications.
The 1075 RPM Multi-Horsepower Condenser Fan Motor delivers dependable airflow and quiet operation for HVAC condenser units. Built with ball bearings, flexible mounting options, and thermal overload protection, it provides long-lasting performance in residential and light commercial systems.
Product Overview
Designed for consistent outdoor HVAC performance, this condenser fan motor operates on 208–230V single-phase power and supports multiple horsepower ratings from 1/6 to 1/3 HP. Featuring Class “B” insulation and a 60°C / 140°F ambient temperature rating, it is well-suited for demanding condenser environments.
Features
- Speed: 1075 RPM
- Horsepower range: 1/6 – 1/3 HP
- Voltage: 208–230V
- Single-phase, 60 Hz
- Ball bearing construction for extended service life
- All-angle mounting capability
- Rheem mounting hole pattern with screws installed
- Thru-bolt or belly band mounting options
- Water slinger on shaft for added moisture protection
- Compatible with air conditioner and heat pump systems
- Insulation class: Class “B”
- Maximum ambient temperature: 60°C / 140°F
- Built-in thermal overload protection
- UL Recognized
