30 µF 370V Oval Capacitor
30 µF 370V Oval Capacitor
SKU: SE3037-O
PRODUCT TYPE: CAPACITORS
High-quality oval capacitor engineered for reliable HVAC motor start and run performance.
The 30 µF 370V Oval Capacitor provides dependable operation for HVAC motors and compressors, offering a compact design ideal for general replacements.
Product Overview
Constructed with a durable aluminum case and metal cap, this capacitor features a polypropylene film medium and metalized film electrodes for consistent and reliable performance. Filled with plant oil according to UL standards, it offers an expected service life of 60,000 hours. Non-PCB design and small dimensions make it ideal for HVAC replacements and safe handling.
Features
- Non-PCB design
- Medium: Polypropylene Film
- Electrode: Metalized Film
- Aluminum case with metal cap (UL compliant)
- Filling material: Plant Oil (UL compliant)
- Expected life: 60,000 hours
- Rated voltage: 370 VAC
- Maximum permitted temperature: 85°C / 185°F
- Terminal ignition time: ≤10 seconds
- Certifications: UL 810, IEC 60242-1, EIA456-A
- Compact dimensions for general replacements
