17.5+4 μF mfd. 370V Dual Oval Capacitor
17.5+4 μF mfd. 370V Dual Oval Capacitor
Reliable oval dual run capacitor designed for residential and commercial HVAC applications.
The SE59-O 17.5+4 µF 370V Oval Dual Run Capacitor features polypropylene film dielectric, metalized film electrodes, and non-PCB construction. Designed for HVAC capacitor replacement applications, it offers an expected service life of 60,000 hours.
Product Overview
The SE59-O Oval Dual Run Capacitor features a capacitance rating of 17.5+4 µF and a rated voltage of 370 VAC. Constructed with an aluminum case and metal cap, it uses polypropylene film dielectric and metalized film electrodes. Its non-PCB construction and UL-compliant filling material are designed for general HVAC replacement applications. With an expected service life of 60,000 hours and a maximum operating temperature of 85°C (185°F), this oval run capacitor is suitable for HVAC equipment requiring these electrical ratings.
Features
- Oval-shaped dual run capacitor
- Capacitance: 17.5+4 µF
- Rated voltage: 370 VAC
- Suitable for general replacement applications
- Compact sizes available
- Non-PCB construction
- Dielectric medium: Polypropylene Film
- Electrode material: Metalized Film
- Aluminum case with metal cap (UL compliant)
- Filling material compliant with UL requirements
- Expected service life: 60,000 hours
- Maximum operating temperature: 85°C / 185°F
- Flame-retardant terminal material; ignition time does not exceed 10 seconds
- Standards: UL 810, IEC 60252-1, EIA-456-A
