40+10 µF 370/440V Dual Oval Capacitor
40+10 µF 370/440V Dual Oval Capacitor
Reliable oval dual run capacitor designed for efficient HVAC motor start and run performance.
The 40+10 µF 370/440V Oval Dual Capacitor delivers consistent, dependable performance for residential and light commercial HVAC systems, making it an excellent option for general replacement applications.
Product Overview
Engineered with a non-PCB polypropylene film dielectric and metalized film electrodes, this oval dual capacitor provides stable electrical performance and long-term durability. The UL-compliant aluminum case with metal cap, combined with a plant oil filling, ensures effective heat dissipation and safe operation. With an expected service life of 60,000 hours, it is well suited for demanding HVAC environments.
Features
- Oval dual capacitor design
- Perfect for general HVAC replacements
- Non-PCB capacitors
- Medium: Polypropylene Film
- Electrode: Metalized Film
- Aluminum case with metal cap (UL compliant)
- Filling material: Plant Oil (UL compliant)
- Expected life: 60,000 hours
- Capacitance: 40+10 µF
- Rated voltage: 370 / 440 VAC
- Maximum permitted temperature: 85º C / 185º F
- Terminal material, ignition time not to exceed 10 seconds
- Certifications: UL 810, IEC 60252-1, EIA456-A
