Condenser Fan Motor - 1/8–1/3 HP - 208/230V - 825/1075 RPM
Condenser Fan Motor - 1/8–1/3 HP - 208/230V - 825/1075 RPM
High-efficiency ECM condenser fan motor for reliable cooling in residential and light commercial HVAC systems.
The Condenser Fan Motor (1/8–1/3 HP) delivers versatile performance with selectable RPM modes, reversible rotation, and easy installation. Surge protection and self-adjusting multi-horsepower design ensure longevity and reliable operation.
Product Overview:
Covers ratings from 1/8 HP to 1/3 HP at 208–230V (825/1075 RPM) and 1/3 HP to 1/2 HP at 208–230V (825/1075 RPM) with both CW and CCW rotation. Easy to install, connecting the same as a standard PSC condenser fan motor. Simply plug into a 115V power source using the supplied programming cable, select one of four operating modes, and install.
- 1075 RPM CW (LE) – Factory Default
- 1075 RPM CCW (LE)
- 825 RPM CW (LE)
- 825 RPM CCW (LE)
An outboard surge protector with wiring harness is included, providing an economical replacement option in case of power surges.
Features:
- Multi-horsepower, self-adjusting design
- 825/1075 RPM selectable speeds
- Reversible rotation (CW/CCW)
- High-efficiency ECM motor
- No capacitor required
- Water slinger on shaft
- UL Recognized
