SPST N.O. Sequencer ON: 1–24 OFF: 40-110
SPST N.O. Sequencer ON: 1–24 OFF: 40-110
Specifications:
Reliable SPST N.O. sequencer designed for precise motor timing control in HVAC systems.
The SPST N.O. Sequencer (ON: 1–24 sec / OFF: 40–110 sec) provides controlled motor start and stop delays for optimal air conditioner and heat pump performance. Designed with 24V operation and full-load rated auxiliary contacts, it’s individually packed for protection and professional use.
Product Overview:
The SPST N.O. Sequencer is engineered to delay motor rotation either at start-up or after cut-off, ensuring efficient system operation while protecting components. It’s widely used in residential and light commercial HVAC systems including air conditioners and heat pumps. Rated at 24V with full-load auxiliary contacts, each unit is individually packed for safe handling and storage.
Features:
- Voltage: 24V
- Full-load rated auxiliary contacts
- ON delay: 1–24 seconds
- OFF delay: 40–110 seconds
- SPST (Single Pole Single Throw) normally open configuration
- Smart sequencer design for delayed motor rotation at start-up or after cut-off
- Individually packed for protection and ease of handling
- Ideal for air conditioners and heat pump applications
