Bi-Directional Filter Drier – SBD-084, 1/2" SAE, 8 cu. in.

Bi-Directional Filter Drier – SBD-084, 1/2" SAE, 8 cu. in.

SKU: SBD-084   PRODUCT TYPE:  REFRIGERATION DRIERS

Solid core bi-directional heat pump filter drier for flow and filtration in both directions.

This SBD-084 Bi-Directional Filter Drier (8 cu.in., 1/2" SAE) includes an internal check valve for filtration in both directions, rated for 680 PSIG working pressure.

Product Overview

Built with an internal check valve, this solid core bi-directional filter drier allows flow and filtration in both directions for heat pump applications. Epoxy powder paint and copper connections support a durable, UL Listed installation rated to a 3400 PSIG bursting pressure.

Features

  • Part No.: SBD-084
  • Shell Volume: 8 cu. in.
  • Connection Size & Type: 1/2" SAE
  • Dimensions: 6.19" x 3.8" x 2.64"
  • Working Pressure: 680 PSIG
  • Bursting Pressure: 3400 PSIG
  • Internal check valve for bi-directional flow and filtration
  • Effectively removes moisture, acid, and solid contaminants
  • Epoxy powder paint
  • Copper connections
  • UL Listed
  • A2L Compatible
